Everyday Desktop Performance

The Intel Core i3-14100 provides four Performance-cores and eight processing threads for everyday productivity, office applications, media use and compatible games.

Clock Speed and Cache

Its Performance-cores operate at a 3.50GHz base frequency and can reach up to 4.70GHz using Intel Turbo Boost Technology 2.0. The processor includes 12MB of Intel Smart Cache and 5MB of L2 cache.

Integrated Graphics

Intel UHD Graphics 730 provides display output without requiring a separate graphics card. It supports Intel Quick Sync Video and up to four displays, subject to the motherboard’s available video connections and system configuration.

Memory Support

The integrated memory controller supports either DDR5-4800 or DDR4-3200, depending on the motherboard. Dual-channel configurations can support up to 192GB with a maximum rated bandwidth of 76.8GB/s.

Platform Connectivity

The processor uses the FCLGA1700 socket and supports PCI Express 5.0 and 4.0 with up to 20 CPU lanes. A compatible Intel 600- or 700-series motherboard with appropriate BIOS support is required.

Power and Cooling

Processor base power is rated at 60W, while maximum turbo power reaches 110W. This boxed version includes an Intel Laminar RM1 cooling solution with pre-applied thermal interface material.

Product Specifications & Identifiers

• Brand: Intel
• Product family: Intel Core i3 processors, 14th Gen
• Processor: Intel Core i3-14100
• Boxed ordering code: BX8071514100
• Spec code: SRMX1
• Code name: Raptor Lake
• Product type: Desktop processor
• Socket: FCLGA1700
• Lithography: Intel 7
• Total cores: 4
• Performance-cores: 4
• Efficient-cores: 0
• Total threads: 8
• Base frequency: 3.50GHz
• Maximum turbo frequency: 4.70GHz
• Intel Smart Cache: 12MB
• Total L2 cache: 5MB
• Processor base power: 60W
• Maximum turbo power: 110W
• Memory support: DDR5 up to 4800MT/s or DDR4 up to 3200MT/s
• Maximum memory capacity: 192GB
• Memory channels: 2
• Maximum memory bandwidth: 76.8GB/s
• Integrated graphics: Intel UHD Graphics 730
• Graphics maximum dynamic frequency: 1.50GHz
• Graphics execution units: 24
• Maximum supported displays: 4
• PCI Express support: PCIe 5.0 and PCIe 4.0
• Maximum CPU PCIe lanes: 20
• Maximum junction temperature: 100°C
• Package dimensions: 45 × 37.5mm
• Included thermal solution: Intel Laminar RM1 cooler
