Desktop Processing Power

The Intel Core Ultra 7 270K Plus combines 8 Performance-cores with 16 Efficient-cores, delivering 24 cores and 24 threads for gaming, content creation and demanding multitasking. Its unlocked multiplier supports performance tuning on a compatible platform.

Performance and Cache

Performance-cores operate at a 3.70GHz base frequency, while the processor can reach up to 5.50GHz using Intel Turbo Boost Max Technology 3.0. A 36MB Intel Smart Cache and 40MB of total L2 cache help keep frequently used data readily accessible.

Memory and Platform Compatibility

The processor supports dual-channel DDR5 memory at speeds up to 7200 MT/s and capacities up to 256GB. It uses the FCLGA1851 socket and is compatible with supported Intel 800-series desktop chipsets, including Z890, B860, H810, Q870 and W880.

Graphics and AI Acceleration

Integrated Intel Graphics provides four Xe cores and a maximum graphics frequency of 2.00GHz, allowing display output without a separate graphics card on a suitably equipped motherboard. Intel AI Boost supplies a dedicated NPU delivering up to 13 TOPS, while overall processor AI capability reaches up to 36 TOPS.

Expansion and Power

Support for PCI Express 5.0 and 4.0 provides up to 24 PCIe lanes for compatible graphics cards and high-speed storage. Processor base power is 125W, with a maximum turbo power of 250W. A compatible LGA1851 cooling solution rated for the processor’s power requirements is necessary.

Product Specifications & Identifiers

• Product: Intel Core Ultra 7 Processor 270K Plus
• Product family: Intel Core Ultra Processors, Series 2
• Architecture codename: Arrow Lake
• Market segment: Desktop
• Total cores: 24
• Performance-cores: 8
• Efficient-cores: 16
• Total threads: 24
• Performance-core base frequency: 3.70GHz
• Efficient-core base frequency: 3.20GHz
• Maximum turbo frequency: 5.50GHz
• Performance-core maximum turbo frequency: 5.40GHz
• Efficient-core maximum turbo frequency: 4.70GHz
• Intel Smart Cache: 36MB
• Total L2 cache: 40MB
• Supported memory: DDR5, up to 7200 MT/s
• Maximum memory capacity: 256GB
• Memory channels: 2
• ECC memory support: Yes, subject to platform support
• Integrated graphics: Intel Graphics
• Graphics cores: 4 Xe cores
• Maximum graphics frequency: 2.00GHz
• NPU: Intel AI Boost
• NPU performance: Up to 13 TOPS
• Overall peak AI performance: Up to 36 TOPS
• PCI Express support: PCIe 5.0 and PCIe 4.0
• Maximum PCIe lanes: 24
• Processor base power: 125W
• Maximum turbo power: 250W
• Socket: FCLGA1851
• Package dimensions: 45mm × 37.5mm
• Maximum operating temperature: 105°C
• Unlocked: Yes
• Manufacturer part number: BX80768270K
• Ordering code: BX80768270K
• Specification code: SA4V6
• Stepping: B0
• Package type: Boxed processor
