> Card unlock and password unlock.
> RS-485 and Wiegand 34 communication (Wiegand 26 can be configured).
> Prompts using the buzzer and indicator light.
> Tamper alarm.
> Watchdog monitors and controls the device when it behaves
> All the connection
Read more..
> Card unlock and password unlock.
> RS-485 and Wiegand 34 communication (Wiegand 26 can be configured).
> Prompts using the buzzer and indicator light.
> Tamper alarm.
> Watchdog monitors and controls the device when it behaves
> All the connection ports have overcurrent and overvoltage protection.
> IP66 rated.
System | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
OSDP Protocol | Yes | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Button Type | Mechanical | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Basic | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Product Type | Card reader | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Buzzer | Yes | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Backlight | Yes | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Casing Material | PC + ABS | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Function | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Unlock Mode | Card, password | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Card Type | ID card | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Performance | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Response Time | 0.1 s | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Card Reading Distance | 0 cm–6 cm (0"–2.36") | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Port | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
RS-485 | 1 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Wiegand | 1 channel output | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Alarm | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Tamper Alarm | Yes | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
General | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Power Supply | 12 VDC, 0.5 A | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Protection | IP66 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Power Consumption | ≤ 0.48 W (standby), ≤ 1.2W (working) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Product Dimensions | 127 mm × 46 mm × 20 mm (5.00" × 1.81" × 0.79") | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Packaging Dimensions | 139 mm × 73 mm × 48 mm (5.47" × 2.87" × 1.89") | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Operating Temperature | –30 °C to +70 °C (–22 °F to +158 °F) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Operating Humidity | ≤ 95% (RH) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Operating Environment | Outdoor | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
> Card unlock and password unlock.
> RS-485 and Wiegand 34 communication (Wiegand 26 can be configu..
