System

Main Processor

Embedded processor

Internet Protocol

IPv4; TCP; UDP

OSDP Protocol

Yes

SDK

Yes

Basic

Product Appearance

Type C Iron Container

Buzzer

Yes

Casing Material

SECC steel board

Function

Unlock Mode

Card swiping; Remote; Password; Fingerprint

Period List

128

Holiday Period

128

Network Update

Yes

First-Card Unlock

Yes

Remote Verification

Yes

Blocklist/Allowlist

Yes

Peripheral Card Reader

8-Channel RS-485 card reader
8-Channel Wiegand card reader

Multi-door Interlock

Yes

Group Combination

Card swiping; password; fingerprint

Real-Time Surveillance

Yes

Multiple Authentication

Yes

User

User (Card) Type

General user; VIP user; patrol user; guest user; blocklist user; other user

Capacity

User

100,000

Fingerprint

3,000

Card

100,000

Record Capacity

500,000

Port

RS-485 Port

9 × RS-485 ports

Wiegand

8 × Wiegand ports

Network

1 × 10/100 Mbps Ethernet port

Alarm Input

8 (digital quantity)

Alarm Output

8 (relay)

Alarm Linkage

Yes

Exit Button

4

Door Status Detection

4

Lock Control

4 channels, NO by default

Alarm

Anti-Passback

Yes

Tamper

Yes

Duress

Yes

Door Unlock Timeout

Yes

Intrusion

Yes

Illegal Card Exceeding Threshold

Yes

Duress Fingerprint

Yes
